User's Guide — 23
(cont'd)
Feed Rate – End Milling
g* ALL CLEARED 0.
1. Select the Process:
2P
END MILLING
2.
2. Select the Tool:
1L
HIGH SPEED STEEL
TOOL 1.
3. Select the Material:
1N
1020-LO C. STEEL
MATL 1.
4. Enter the # of Teeth:
4gI (#Teeth)
NUMBER OF TEETH
4.
5. Enter the Width of Cut:
.25gP (WOC)
WIDTH OF CUT
0.25 INCH
6. Enter the Length of Cut:
20gL (LOC)
LENGTH OF CUT
20. INCH
To Next Page
