42 — Machinist calc
®
Pro 2
4gt (Thread Class)
MM INT. THREAD
4H
4.
2. Scroll through the available Tolerance Positions for the
entered Grade:
t
MM EXT. THREAD
4g 4.
t
MM EXT. THREAD
4h 4.
t
MM EXT. THREAD
4e 4.
t
MM EXT. THREAD
4f 4.
t
MM INT. THREAD
4G 4.
t
MM INT. THREAD
4H 4.
3. Enter a Tolerance Grade of 6 and scroll through the
available Tolerance Positions for the entered Grade:
6gt (Thread Class)
MM INT. THREAD
6H 6.
t
MM EXT. THREAD
6g 6.
t
MM EXT. THREAD
6h 6.
t *
MM EXT. THREAD
6e 6.
* Repeated presses of t will continue to scroll through the
available Tolerance Positions of the specified Grade.
Note: The number 3 can be entered to select both U.S. and Metric
classes. To select either, go to Preferences and set the calculator to
either U.S. Mode or Metric Mode.
(cont'd)
