48 — Machinist calc
®
Pro 2
t
ROLL TAP DRILL
#14 0.182 INCH
t
CLOSE FIT DRILL
5.300 MM
t
FREE FIT DRILL
5.800 MM
t
PITCH DIAMETER
MIN 4.513 MM
t
PITCH DIAMETER
MAX 4.588 MM
t
MINOR DIAMETER
MIN 4.188 MM
t
MINOR DIAMETER
MAX 4.306 MM
t
MAJOR DIAMETER
MIN 5.000 MM
5. Switch to External 4g Tolerance Class:
gtt (Thread Class)
MM EXT. THREAD
4g 4.
6. Clear the display and find the available External Thread
characteristics:
O
0.
t
THREAD SIZE
4g 5. - 0.75 MM
t
ROD SIZE
5.000 MM
t
COLD FORM SIZE
4.452 MM
t
PITCH DIAMETER
MAX 4.491 MM
(cont'd)
