10. Top Assembly Replaceable Parts – BPS75, BPS90, BPS150 and BPS180
Models.
Note that different generation and model BPS units may use different sub assemblies. Check the serial tag on the
back of the BPS to determine the applicable top assembly number to determine the correct sub assembly or part
required. For amplifiers, refer to the amplifier serial tag for the relevant amplifier top assembly part number.
Table 10-1: BPS75/BPS90, BPS150 and BPS180 - Replaceable Parts & Fuses
Ref. CI P/N Description Vendor
Qty
Location
Oscillator Assembly 7003-442
A2 7003-442-1 Front Panel Assy. Prog. Osc. AMETEK PP 1
A2-A9 7000-723-4 Keyboard/Display assy. AMETEK PP 1
A2-A5 7003-715-3 PC Assy. Indicator AMETEK PP 1
A2-A7 7003-718-7 CPU board assy. All 3 phase AMETEK PP 1
A2-A11 7003-719-1 PC Assy. Aux Generator AMETEK PP 1
Top Assembly 5440001
A1 7003-721-6 PC Assy, RS232/GPIB/USB AMETEK PP 1
A14 7003-722-1 PC Assy, Low Volt PSU AMETEK PP 1
A15 7003-722-1 PC Assy, Low Volt PSU AMETEK PP 1
A16 7003-723-1 Ripple Filter AMETEK PP 1
A3 7003-731-1 PC Assy., System Interface AMETEK PP 1
A4,A5 7003-701-1 PC Assy., V / I Sense AMETEK PP 2
A13 7003-714-1 PC Assy., EMI Filter AMETEK PP 1
A7 7003-448-1 Amplifier Assy., 15kVA AMETEK PP 1
A8 7003-448-1 Amplifier Assy., 15kVA AMETEK PP 1
A9 7003-448-1 Amplifier Assy., 15kVA AMETEK PP 1
A10 7003-448-1 Amplifier Assy., 15kVA AMETEK PP 1
A11 7003-448-1 Amplifier Assy., 15kVA AMETEK PP 1
A12 7003-448-1 Amplifier Assy., 15kVA AMETEK PP 1
B1, B2 241186 Fan, 3", 24VDC NMB Technology
3110KLO5WB50-P00
2
B3, B4 853-230-77 Fan, 6-3/4”, 230VAC Orion
OA172SAP-22-1TB
2
CB1 270224 Circuit Breaker, 2.5A, 300V AIRPAX
IELH111-1-61-2-50-D-01-V
1
K1A
K1B
245235 Relay, 3C, 30A, 24VDC Deltrol Controls
21014 - 82
2
K8 245235 Relay, 3C, 30A, 24VDC Deltrol Controls
21014 - 82
1
K2A
K2B
K6, K7,
K9
245248 Relay, 3C, 100A, 24VDC
ABB
AE75-30-00-81 5
K5 852-145-00 Contactor, 3 Pole, 230A ABB
AF145-30-00-72
1
K3 5440065-01 Relay Assy, 250A Ametek PP
R1-R6 811-12R-17 Res, 12 ohm, 175W, Rib-wound Milwaukee Resistor
061807212.000EBRKT
6
