5.2.10 OUTPUT CAL FACTORS Menu
Figure 5-24: OUTPUT CAL FACTORS Menu (Series II only)
The OUTPUT CAL FACTORS menu provides access to the output calibration parameters. These
parameters are password protected and can only be changed after the calibration password has been
entered. For three phase configurations, the PHASE keys toggle between the three calibration screens for
each phase. Refer to the calibration section in this manual for details on performing a calibration.
The following calibration factors are available from this menu:
Entry Description
VOLT FS Full scale voltage output calibration factor.
VOLT ZERO Zero offset voltage calibration factor.
PHASE OFST Phase offset calibration factor. Compensates for phase shift caused by
AC amplifier.
