4.7 Connectors - Rear Panel
A number of connectors are located along the center rear panel. These connectors are in a recessed area to
protect them from shipment damage.
4.7.1 System Interface
WARNING: The system interface connectors are for use with AMETEK Programmable Power
supplied cables, and only between California Instruments equipment.
A set of two identical System Interface connectors, P8 and P9 ( TBD ) is located on the rear panel of each
BPS chassis. The system interface is used to connect the multiple BPS power sources in a
Master/Auxiliary configuration to create BPS150 or BPS180 models. In these configurations, only the
Master BPS power source has a built-in controller and front panel.
P8 / P9 Description
1 OUTP: Output ON. Controls state of output relay
2 N/C
3 N/C
4 N/C
5 COM: Common. Signal return.
6 OT: Over temperature. Indicates over temperature condition.
7 N/C
8 CLB: Current Limit B. Programmed current limit reference for phase B
9 CSA: Current Sum Phase A
10 CSC: Current Sum Phase C
11 FLT A: Amplifier Fault Phase A
12 FLT C: Amplifier Fault Phase C
13 XFMR: Optional voltage range select. (-HV or -XV option)
14 PARALLEL: Parallel operation control.
15 INPUT ON: Input power status
16 A ERR LO: Error Signal Phase A, low
17 B ERR HI: Error Signal Phase B, high
18 N/C
19 C ERR LO: Error Signal Phase C, Low
20 300 VRNG: 300 V AC Range Select
21 COM: Common. Signal return.
22 /REM OFF: Remote Off Control not
23 COM: Common. Signal return
24 FLK/BYP: Flicker / Bypass OMNI control
25 /OVL: Overload not
