AMETEK Programmable Power
BPS Series User Manual M440077-01 Rev A 20
2.6.1 -HV Option Specifications
The -HV option provides an AC only output range of 0 to 400 Vac L-N. Specifications unique to the -HV
option are shown in the table below.
Output Parameter BPS30 BPS45 BPS75 BPS90 BPS150 BPS180
Modes:
Single or three phase depending on model.
Voltage:
Ranges (L-N): 0 -400 V
Resolution: 0.1 V
Accuracy: ± 0.25% of Full Scale / ± 1.0 Vac rms
Output Coupling AC only
Power: (total power for all phases, either range, at full scale voltage)
AC Mode 30 KVA 45 KVA 75 KVA 90 KVA 150 KVA 180 KVA
Current:
Note: Current, maximum amps per phase available between 50 and 100 % of voltage range.
AC Mode
Single Phase
BPS30-1,
400V, single
phase
V Hi: 75A
BPS45-1,
400V, single
phase
VHi:112.5A
N/A
N/A
N/A
N/A
AC Mode
Three Phase
BPS30-3,
400V, per
phase
V Hi: 25A
BPS45-3,
400V, per
phase
V Hi: 37.5A
BPS75-3,
400V, per
phase
V Hi: 62.5A
BPS90-3,
400V, per
phase
V Hi: 75A
BPS150-3,
400V, per
phase
V Hi: 125A
BPS180-3,
400V, per
phase
V Hi: 150A
Peak Current:
AC Mode
Single Phase
BPS30-1,
400V, single
phase
VHi: 225A
BPS45-1,
400V, single
phase
VHi:337.5A
N/A
N/A
N/A
N/A
AC Mode
Three Phase
BPS30-3,
400V, per
phase
V Hi: 75A
BPS45-3,
400V, per
phase
VHi:112.5A
BPS75-3,
400V, per
phase
VHi:187.5A
BPS90-3,
400V, per
phase
V Hi: 225A
BPS150-3,
400V, per
phase
V Hi: 375A
BPS180-3,
400V, per
phase
V Hi: 450A
Frequency:
Range: 45 Hz – 819 Hz
with –LF option: 45 Hz – 500 Hz
Note: Output specifications apply below the Current / Voltage rating lines shown in the following
V/I rating charts.
