User Manual AMETEK Programmable Power
BPS Series 50
4.7.3 BNC Connectors
BNC connectors. Functions are called out on rear panel decal. Table shows connections from left to right
when standing at the rear of the BPS cabinet.
Table 4-6: BNC Connectors
BNC Description
1 Trigger Input (TTL input)
2 Trigger Output (TTL output) (Same signal connection as Function Strobe. Some units may not
have this output connected. If you don’t get an output trigger on this BNC, use the Function Strobe
BNC instead.)
3 Function Strobe (TTL output) (Same signal connection as Trigger Output)
4 Clock (TTL output on Master / TTL input on Auxiliary). Not available on all models.
5 Lock (TTL output on Master / TTL input on Auxiliary) .Not available on all models.
6 Emergency Shut off inter connect. Not required on single master systems.
Table 4-7: BNC Connectors
4.7.4 External Sense Connector
Pin Description
1 Phase A sense
2 Phase B sense
3 Phase C sense
4 Neutral sense
Table 4-8: External Sense Connector
