BPS Series 66
The following top-level menu choices can be accessed from the MENU key:
Entry Description
MENU 1
PROGRAM The PROGRAM menu allows output parameters the be changed.
MEASUREMENTS The MEASUREMENTS screens are not menus in that no user entries
are required.
TRANSIENTS The TRANSIENTS menu allows output transients to be programmed.
WAVEFORMS The WAVEFORMS menu allows different waveforms to be selected
from the waveform library. Not available on all models.
MORE The MORE selection causes the second part of the MENU screen to
be displayed. (MENU 2)
MENU 2
ADVANCED MEAS. The ADVANCED MEAS. screens are for display only. No user
entries are required. Not available on all models.
APPLICATIONS The APPLICATIONS menu provides access to the optional firmware
application programs that may be installed in the BPS Series AC
source. Not all applications are available on this model power source.
SETUP REGISTERS The SETUP REGISTERS menu allows complete instrument settings
and transient list programs to be saved to nonvolatile memory.
MORE The MORE selection causes the third part of the MENU screen to be
displayed. (MENU 3)
MENU 3
UTILITY The UTILITY menu provides access to less commonly used setup
screens such as those for the GPIB and RS232C (also applies to USB
and LAN) interface settings, initial startup values, etc.
MEASUREMENT CAL The MEASUREMENT CAL menu allows for calibration of the AC
source measurement system.
OUTPUT CAL The OUTPUT CAL menu allows for calibration of the AC source
output.
Following the Menu overview pages is a detailed description of each menu and sub menu.
