⑰ ⑱ ⑲ ⑳ ㉑ ㉒ ㉓ ㉔
Page 12 - Manual FB00942-EN - ver. 1 - 11/2017 - © CAME S.p.A. - The contents of this manual are subject to change at any time without prior notice.
CAUTION!
The device should only be cleaned using a soft cloth dampened with water.
⑰
Reset button.
⑱
Setting the clock.
⑲
Setting the operating parameters.
⑳
Selecting the operating mode:
COOLING
HEATING or OFF .
㉑
Selecting the user profile.
㉒
Selecting window contact or remote operation.
㉓
Setting the frost protection temperature.
㉔
Displaying the system operating time for temperature level.
Function of internal buttons
To access the internal command buttons, pull out the tab ⑬ and then the unit body from
the frame.
