CAME BXV Series User Manual

p. 23 - Manual FA01294-EN - 12/2018 - © CAME S.p.A. - The contents of this manual may change, at any time, and without notice. - Original instructions
Additional light
It allows to choose the operating mode of the lighting device connected to the output.
F18 Additional light 0 = Flashing light (Default)
1 = Cycle light
The light remains off if an automatic closing time is not set.
Cls. Automatic
Sets the time that must pass before the automatic closing is activated, once the opening travel end has been reached.
The function does not work if any of the safety devices trigger when an obstruction is detected, or after a total stop, or during a power outage.
F19 Cls. Automatic OFF (Default)
From 1 to 180 seconds
Automatic closing time after partial opening
Sets the time that must pass before the automatic closing is activated, after a partial opening command has been performed.
The function does not work if any of the safety devices trigger when an obstruction is detected, or after a total stop, or during a power outage.
Do not deactivate the function [Automatic closing].
F20 Automatic closing time after
partial opening
OFF
From 1 to 180 seconds (10 seconds Default)
Pre-flashing time
Sets the early activation time before each manoeuvre.
F21 Pre-flashing time OFF (Default)
From 1 to 10 seconds
Opening speed
Sets the opening speed (percentage of maximum speed).
F28 Opening speed from 60% to 100% (Default)
Slow-down speed
Sets the slowing down speed during opening and closing (percentage of maximum speed).
This function appears only is the Encoder function is active.
F30 Slow-down speed From 10% to 50% (Default)
Travel sensitivity
It adjusts the obstruction detection sensitivity during the gate travel.
F34 Travel sensitivity from 10% to 100% (Default) - 10% = maximum sensitivity - 100% = minimum
sensitivity
Slow-down sensitivity
Adjusts the obstacles detection sensitivity level during the slowdown phase.
F35 Slow-down sensitivity from 10% to 100% (Default) - 10% = maximum sensitivity - 100% = minimum
sensitivity
Partial open point
Adjusts the operator partial opening (percentage of total travel).
This function appears only is the Encoder function is active.
F36 Partial open point From 10% (Default) to 80%

CAME BXV Series Specifications

General

Encoder	Yes
Power Supply	230V AC, 50Hz
Max Door Weight	800kg
Duty Cycle	30%
Lifting Capacity	800kg
Power Consumption	370W
Remote Control	Yes
Battery Backup	Optional
