CT-MCL01 l User’s Manual
13
1.2.4 Layout Content List
Chapter 1: Product Introductions
Slots & sockets
Label Function Note
CPU1
LGA
1151 socket
DIMMA1~B2 (X)
DDR4 DIMM Slot A1~B2
PCIEX16_1 (G)
PCI
-e x16 Slot
PCIEX1_1 (H)
PCI
-e x1 Slot
PCIEX4_1 (I)
PCI
-e x4 Slot
PCIEX4_2 (J)
PCI
-e x4 Slot
Jumpers
Label Function Note
JCMOS1 (B1)
Clear CMOS
3 x 1 header, pitch 2.54mm
JPSON1 (C1)
AT/ATX Mode Select
3 x 1 header, pitch 2.54mm
Rear Panel Connector
Label Function Note
COM12 (A)
2
COM port connector
COM1(upper)+COM2(lower)
DP1+DP2 (B)
DP+
DP connector
DP1(upper)+DP2(lower)
DVI
-D1+VGA1 (C)
DVI
-D+ VGA connector
VGA(upper)+DVI(lower)
LAN1_USB12 (D)
RJ
-45 Ethernet Connector x 1
USB
3.1 Gen2 Connector x 2
LAN2_USB34 (E)
RJ
-45 Ethernet Connector x 1
USB
3.1 Gen2 Connector x 2
AUDIO1 (F)
3
port audio jack
Light Blue: Line
-in, Lime: Line-
out, Pink: Mic
-in
