Specifications Summary
System
• CPU: Intel® LGA1151 socket supports Intel® Core™
i7/ i5/ i3 CPU
• BIOS: AMI 256MB SPI ROM
• System Chipset: Intel® Q370
• Memory: 4x DIMM Up to 64GB Dual Channel DDR4
2133/2400/2666 (depend on CPU) MT/s
• Watchdog Timer: 1~255 sec timer
• H/W Status Monitor:
- CPU & system temperature monitoring
- Voltages monitoring
• Expansion Slots
- 1 x PCIe x 16 Slot (Black)
- 2 x PCIe x 4 Slot (Black)
- 1 x PCIe x 1 Slot (Black)
- 1 x M.2 M / NVMe PCIe x 4 / SATA / 2242, 2260,
2280
- 1 x M.2 E / PCIe x2 / USB 2.0 / 2230
• Smart Fan Control: Yes
Display
• Chipset: Intel® Integrated Graphic (CPU Dependent)
• Display Memory: Shared Memory
Ethernet
• LAN1: Intel® I219-LM PHY LAN Controller
• LAN2: Intel® I211-AT PCIe LAN Controller (Co-Lay
Intel® I210-AT)
Back I/O Port
• Back Panel
- 2 x RS-232/422/485 DB9 Connector
- 2 x Display Port Connector
- 1 x VGA Connector
- 1 x DVI-D Connector
- 2 x Stack up RJ45 and USB 3.1 Gen 2 Connectors
- 1 x 3 Jacks Audio Connector
Internal I/O Connector
• Intel I/O
- 6 x SATAIII connectors(RED) (SATA1 shared with
M.2 M key)
- 4 x USB 2.0 headers support 7 ports
- 1 x USB 3.1 Gen1 box header support 2 port
- 4 x RS232 2.00 mm box header
- 1 x LPC box header
- 1 x SPI header
- 1 x Front Audio header
- 1 x CPU Fan connector
- 2 x SYS Fan connector
- 1 x Front panel header
- 1 x 8 bits GPIO box header
- 1 x Horizontal Socket Type CMOS Battery Holder
- 1 x 24-pin ATX Power connector
- 1 x 8-pin ATX 12V Power connector
Mechanical & Environment
• Operating Temp.: 0°C ~ 60°C (32°F ~ 140°F)
• Operating Humidity: at 40C 95% relative humidity,
non-condensing
• Size (L x W): 9.6 inch x 9.6 inch
