CT-MCL01 l User’s Manual
39
2.5 ACPI function
Chapter 2: BIOS Setup
Wake-up Devices and Events
These devices/events can
wake up the computer…
from this state Remarks
PCIE LAN
S3, S4, S5
• The LAN adapter monitors network traffic at the Media
Independent Interface
•
Supports LAN wake capabilities with ACPI by Ping or
Magic Packet
•
S3-S4 by OS
•
S5 by BIOS item control
Intel GBE
S3, S4, S5
•
S3-S5 BIOS control.
PME# signal
S3, S4, S5
•
PME# signal on the PCI bus
•
S3-S4 by OS control
•
S5 by BIOS item control
Wake# signal
S3, S4, S5
•
WAKE# signal on the PCI Express bus
•
S3-S4 by OS control
•
S5 by BIOS item control
Power switch
S3, S4, S5
RTC alarm
S5
USB
S3,S4
•
Press any key or move can wake up system
•
S3,S4 by OS control
Notes:
•
Does not apply to shutdown system by delay 4 seconds.
Sleep
Wake State
Source
S1 S3 S4 S5
PCIE LAN
х
◎ ◎
△
Gbe LAN
х
△ △ △
PME#/WAKE#
х
◎ ◎
△
Power Button
х
◎ ◎ ◎
RTC Alarm
х х х △/◎
USB
х
◎ ◎
х
х : No Support.
△ : Controlled by BIOS Item. ◎ : Controlled by OS/Driver.
