CT-MCL01 l User’s Manual
38
2.3 BIOS Hotkey Requirements
The table below lists the BIOS hotkey requirements.
2.4 South Bridge Features
Chapter 2: BIOS Setup
POST Error Beep Requirements
Item Description Remarks
PCI Express
•
PCIE LAN by root port control enable/disable.
•
PCIE RAID, LAN onboard devices must included
option ROM and add control item in BIOS
SATA & RAID
•
Supports RAID and AHCI configuration and can
operate in both legacy and native modes.
•
Support over 2T capacity HDD.
PCI Bus Interface
•
Onboard PCI LAN can enable/disable by BIOS.
•
PCI RAID, LAN onboard devices must included
option ROM and add control item in BIOS
USB Interface
•
Support USB 2.0 (High Speed)
•
Support USB 3.0 (Super High Speed)
•
Per-Port-Disable /Enable Capability
•
Support Keyboard/Mouse wake-up from sleeping
S3/S4 by OS.
•
Support legacy Keyboard/Mouse software
•
Support legacy Keyboard Hot-Plug function
•
Support maximal 8 USB devices in Boot Option
Priority.
Real
-Time Clock
•
System can be wake up from S5 by RTC.
•
User can set day and time to active RTC function.
•
RTC time can’t be clear when short RTCRST#
•
RTC works even power has been loss.
BIOS Hotkey Requirements
Hot Key
Enter BIOS Setup
DEL / ESC
