2.15 F
ILM TRANSPORT
UNIT DISASSEMBLY
Fig. 3-46 Film transport unit disassembly
Part 3: Repair Information
3-32
★NK-74C
Inner friction surface
★Bond 1401C
Screw head
* Logenest Lambda A-74
Apply light coat on gears, gear
shafts, and springs.
4.5mm x2
3.0mm x3
x3
