Part 2: Technical Information
2-16
Fig. 2-19 Overall Operation and Basic Time Chart
CLOSE
Perforation detection
For one frame during continuous shooting at about 3.5 fps
OPEN
CLOSE
OPEN
SW-2
SW-1
M1
Lens Driving
Mirror Operation
EMD
Autofocusing & Metering
DATE
Film
Mg3-1 Mg3-2
Start 100 200 300 400 500ms
Mirror-up
Reverse
Shutter cocked
Mirror down
Reverse
Film rewind
Forward
Mirror-up
Reverse
Equipment: EOS ELAN 7 E / EOS 30 + USM Lens
Camera operation during AI Servo AF continuous shooting with autofocus achieved and SW-2 ON from the SW-1 position.
2nd frame onward
AF • AE
Lens driven
Film advanced
Actual exposure
SW-1 position
Aperture stopped
down
Mirror up
Mirror down
Shutter cocked
Aperture stopped
down Mirror up
Shutter cocked
Mirror down
Reverse
Film rewind
Forward
