No. Code Applicable Unit Function
172 YBASIS FINDER(EYE) Eye Control AF sensor
173 CYE2 FINDER(EYE) YBASIS power source-stabilizing capacitor
174 CYVC1 FINDER(EYE) YBASIS standard voltage-stabilizing capacitor
175 RY1 FINDER(EYE) BCLK noise-control resistor
176 YIRED0 FINDER(EYE) Eye Control illumination LED
177 YIRED1 FINDER(EYE) Eye Control illumination LED
178 YIRED2 FINDER(EYE) Eye Control illumination LED
179 YIRED3 FINDER(EYE) Eye Control illumination LED
180 YIRED4 FINDER(EYE) Eye Control illumination LED
181 YIRED5 FINDER(EYE) Eye Control illumination LED
182 YIRED6 FINDER(EYE) Eye Control illumination LED
183 YIRED7 FINDER(EYE) Eye Control illumination LED
184 DX1 TOP High-voltage flash countering diode
185 DX2 TOP High-voltage flash countering diode
186 CX TOP High-voltage flash countering capacitor
187 RX TOP High-voltage flash countering resistor
188 FCCC TOP EMI countering coil
189 FEFID TOP EMI countering coil
190 REMU RLS Wireless remote control sensor
191 CREM RLS Wireless remote control’s power source-stabilizing
capacitor
192 SPLED1 SI Superimposition LED
193 SPLED2 SI Superimposition LED
194 SPLED3 SI Superimposition LED
195 SPLED4 SI Superimposition LED
196 SPLED5 SI Superimposition LED
197 SPLED6 SI Superimposition LED
198 SPLED7 SI Superimposition LED
199 AFIC AF AF sensor
200 CVCCAF AF AF sensor power source-stabilizing capacitor
201 CVRES AF AF sensor internal power source-stabilizing
capacitor
202 CVGR AF AF sensor internal power source-stabilizing
capacitor
203 CVDDAF AF AF sensor power source-stabilizing capacitor
204 CVCAF AF AF sensor internal power source-stabilizing
capacitor
205 RMOSI AF AF sensor noise-countering capacitor
206 RCLKAF AF AF sensor noise-countering capacitor
207 LAF AF AF sensor noise-countering coil
208 DTEMP AF AF temperature detection diode
209 RTEMP AF AF sensor resistor
Part 2: Technical Information
2-29
