Canon imagePROGRAF iPF760 User Manual

• The Ink Tank Cover is open
Close the Ink Tank Cover.
• The Printhead is not installed
see "Replacing the Printhead." →P.577
• An Ink Tank is not installed
see "Replacing Ink Tanks." →P.568
• If ERROR is shown on the Display Screen
see "Error messages." →P.632
•
The Power Lamp and Message Lamp are not lit (even once), and nothing appears on the Display Screen
Make sure the printer is plugged in correctly. Check the connection at the plug and electrical outlet.
• No paper is loaded
Load paper. (See "Loading and Printing on Rolls.") →P.21 (See "Loading and Printing on Sheets.")
→P.24
Important
• Starting the printer when it is connected via the USB cable to a Macintosh computer that is off may cause the computer to
start up at the same time. To prevent this, disconnect the USB cable before starting the printer. Connecting the printer to the
computer via a USB hub may solve this issue.
Turning the printer off
Important
• Never disconnect the printer's power supply or unplug it during a print job. This may damage the printer.
1
Make sure no print jobs are in progress.
If the Message Lamp is flashing, check the message on the
Display Screen and take action as necessary. (See "Error
Messages.") →P.632
Turning the Printer On and Off iPF760
User's Guide
Basic Printing Workflow Printing procedure
20

Canon imagePROGRAF iPF760 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
