Canon imagePROGRAF iPF760 User Manual

Open the Binding Settings dialog box.
3 If the Binding checkbox is not checked, select it to turn binding on.
4 Select Binding Edge.
5 Select Binding Margin.
6
Click the OK button.
Return to the Layout screen.
Check that the Binding settings are applied in the pre-
view screen.
7 Configure the settings in the Printing Wizard dialog box.
Configuring Special Settings
Configuring Special Settings
You can configure Special Settings from the imagePROGRAF Print Plug-In toolbar.
1
Click imagePROGRAF in the toolbar, and select Spe-
cial Settings.
2 Turn the checkbox for the item you want to change on or off.
Item Details
Show progress indicator during plug-in startup When this setting is off, hides the progress indicator that appears while the plug-
in is starting up.
iPF760 Configuring Special Settings
User's Guide
Windows Software Print Plug-In for Office
291

Canon imagePROGRAF iPF760 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
