Canon imagePROGRAF iPF760 User Manual

Settings Summaries Dialog Box
Settings Summaries Dialog Box
The Settings Summaries dialog box enables you to confirm the settings for the Main, Page Setup, Layout, and Fa-
vorites sheets.
• A Copy
Click to copy the settings information to the clipboard. You can paste the settings information into a file created
with a text editor or similar application.
Device Settings Sheet
Device Settings Sheet
Many settings items on the printer properties sheets are controlled by Windows applications. However, the Device Set-
tings sheet is for configuring the printer, and it is an extension of the printer driver.
The following settings are available on the Device Settings sheet.
Settings Summaries Dialog Box
iPF760
User's Guide
Windows Software Printer Driver
206

Canon imagePROGRAF iPF760 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
