Canon imagePROGRAF iPF760 User Manual

Paper Settings Panel
Paper Settings Panel
This panel appears when you select Paper Settings in the dialog area.
• Media Type
This allows you to select the media type.
Note
• Always select media type that is actually set in the printer. When the media you chose is different from the media set in
the printer, you may not receive the desired print results.
•
Easy Settings / Advanced Settings
Two modes are available to provide the optimum print settings for jobs.
The settings available on each mode are as follows.
• Easy Settings →P.375
• Advanced Settings →P.376
•
Paper Source
You can select the paper source.
The following settings are available for paper source.
Setting Details
Manual Select for manual paper feed printing.
Roll Paper Select to print on roll paper.
iPF760
Paper Settings Panel
User's Guide
Mac OS X Software Free Layout
373

Canon imagePROGRAF iPF760 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
