4
Move the Width Guide (a) carefully to match the size of pa-
per loaded.
Set the Width Guide against the edge of the paper to prevent
the paper from becoming crooked or wrinkled.
5
Press the OK button.
If a print job was received
The printer now starts printing the print job.
If no print job was received
A menu for selection of the type of paper is automatically shown on the Display Screen.
Press or to select the type of paper, and then press the OK button.
The printer now starts feeding the paper.
Note
For details on types of paper to select, see the Paper Reference Guide. (See "Types of Paper.") →P.434
Printing From a Desired Starting Point
Printing From a Desired Starting Point
When printing inside boundaries or in other situations when you want to specify a particular position to start printing
from, set Width Detection to Off in the printer menu for the type of paper used.
Set Width Detection to Off
1
On the Tab Selection screen of the Control Panel, press or to se-
lect the Paper tab (
).
Note
If the Tab Selection screen is not displayed, press the Menu button.
iPF760
Printing From a Desired Starting Point
User's Guide
Handling Paper Handling sheets
463

Table of Contents

Other manuals for Canon imagePROGRAF iPF760

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Canon imagePROGRAF iPF760 and is the answer not in the manual?

Canon imagePROGRAF iPF760 Specifications

General IconGeneral
ColorYes
Printing colorsBlack, Cyan, Magenta, Pigment matte black, Yellow
Print technologyInkjet
Maximum resolution2400 x 1200 DPI
Number of print cartridges5
Page description languagesGARO, HP-GL/2, HP-RTL
Media thickness0.8 mm
Maximum print size-
Maximum roll length18 m
Media width (rolls)254 - 914.4 mm
Media width (sheets)203.2 - 917 mm
Maximum roll diameter150 mm
ISO A-series sizes (A0...A9)A0, A1, A2, A3
ISO B-series sizes (B0...B9)B1, B2, B4
CertificationCE, RoHS, ECO, WEEE
Sound power level (standby)35 dB
Sound pressure level (printing)50 dB
USB connectorUSB Type-A
USB 2.0 ports quantity1
Ethernet interface typeGigabit Ethernet
Sustainability certificatesENERGY STAR
Power requirements100 - 240V, 50/60Hz
Power consumption (standby)0.5 W
Power consumption (typical)140 W
Operating temperature (T-T)15 - 30 °C
Operating relative humidity (H-H)10 - 80 %
Compatible operating systemsWindows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)1304 x 1100 x 1062 mm
