Print area Normal size Printable area
•
Rolls
3 mm (0.12 in) from each side
•
Sheets
3 mm (0.12 in) from the top, 23 mm (0.91 in) from the bottom, and 3mm (0.12
in) from the left and right sides
For information on the recommended print area, see "Print Area." →P.656
Borderless printing (*2) Printable area (rolls)
0 mm from the top, 0 from the bottom, and 0 mm from the left and right sides
Supported width for borderless printing 36-in. Roll (914.4mm), ISO A0/A1 Roll (841.0mm), JIS B1/B2 Roll (728.0mm),
24-in. Roll (609.6mm), ISO A1/A2 Roll (594.0mm), JIS B2/B3 Roll (515.0mm),
17-in. Roll (431.8mm), ISO A2/A3 Roll (420.0mm), 14-in. Roll (355.6mm),
300mm Roll (300.0mm), ISO A3/A4 Roll (297.0mm), JIS B4 Roll (257.0mm), and
10-in. Roll (254.0mm)
*1: Printing may not be possible in some cases, depending on the type and size of paper.
*2: Varies depending on the operating system or application.
Options
Roll Holder Set RH2-33
Print Area
Print Area
A margin required by the printer is added with respect to the size of paper loaded in the printer. Except in borderless
printing, the actual printing area corresponds to the paper size minus the space for this margin.
Note
• Printable Area: The area that can be printed.
• There is no margin (that is, a margin of 0 mm) during borderless printing on rolls.
• Recommended Print Area: We recommend printing within this area.
• To print so that your original matches the print area exactly, use an oversized paper size that includes the required margin.
(See "Printing on Oversized Paper.") →P.86
Margins of Printable Area Margins of Recommended Print Area
Top Edge Bottom Edge Sides Top Edge Bottom Edge Sides
Sheets 3 mm (0.12 in) 23 mm (0.91 in) 3 mm (0.12 in) 20 mm (0.79 in) 23 mm (0.91 in) 5 mm (0.20 in)
Rolls 0/3 mm (0/0.12 in) 0/3 mm (0/0.12 in) 0/3 mm (0/0.12 in) 20 mm (0.79 in) 5 mm (0.20 in) 5 mm (0.20 in)
Sheets
Print Area
iPF760
User's Guide
Specifications Printer Specifications
656
To Next Page
