Canon imagePROGRAF iPF760 User Manual

For more information about Borderless Printing, see "Print with No Borders." →P.364
Note
• Available only if rolls are selected in Paper Source.
• This is not displayed when a checkmark is placed in Print Centered.
• Paper Size
You can select the size of the print media.
Note
• This is not displayed when Fit Roll Paper Width is set in Enlarged/Reduced Printing.
•
Print Centered
You can print on the center of the media loaded in the printer.
For more information about Print Centered, see "Print on the Center." →P.365
Note
• This is not displayed when a checkmark is placed in Borderless Printing.
•
No Spaces at Top or Bottom
You can save paper on not to feed roll paper for the empty spaces when the print data contains spaces at the top
or bottom.
For more information about No Spaces at Top or Bottom, see "Not Print Spaces at the Top/Bottom." →P.365
Note
• Available only if rolls are selected in Paper Source.
•
Rotate Page
Select the method for rotating page.
The following settings are available for rotating page.
Setting Details
Rotate Right 90 Degrees Rotates the portrait page right 90 degrees and print in landscape orientation. When the rotated
page can fit in the width of roll paper, the page is rotated automatically, and when it can not fit in
the width of roll paper, the page is not rotated.
Rotate Left 90 Degrees Rotates the portrait page left 90 degrees and print in landscape orientation. When the rotated
page can fit in the width of roll paper, the page is rotated automatically, and when it can not fit in
the width of roll paper, the page is not rotated.
Rotate 180 degrees Allows you to rotate the image 180 degrees from the vertical to the right.
•
Restore Defaults Button
Click the button to reset to the setting when starting Preview.
•
Print
Button
Click the button to begin printing.
• Update Printer Info.
Button
Click the button to acquire printer information.
iPF760
Output Settings Panel
User's Guide
Mac OS X Software Preview
355

Canon imagePROGRAF iPF760 Specifications

General

Color	Yes
Printing colors	Black, Cyan, Magenta, Pigment matte black, Yellow
Print technology	Inkjet
Maximum resolution	2400 x 1200 DPI
Number of print cartridges	5
Page description languages	GARO, HP-GL/2, HP-RTL
Media thickness	0.8 mm
Maximum print size	-
Maximum roll length	18 m
Media width (rolls)	254 - 914.4 mm
Media width (sheets)	203.2 - 917 mm
Maximum roll diameter	150 mm
ISO A-series sizes (A0...A9)	A0, A1, A2, A3
ISO B-series sizes (B0...B9)	B1, B2, B4
Certification	CE, RoHS, ECO, WEEE
Sound power level (standby)	35 dB
Sound pressure level (printing)	50 dB
USB connector	USB Type-A
USB 2.0 ports quantity	1
Ethernet interface type	Gigabit Ethernet
Sustainability certificates	ENERGY STAR
Power requirements	100 - 240V, 50/60Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	140 W
Operating temperature (T-T)	15 - 30 °C
Operating relative humidity (H-H)	10 - 80 %
Compatible operating systems	Windows XP/Server 2003/Server 2008/Vista/7\\r Mac OS 10.5 - 10.7.x

Weight and Dimensions

Dimensions (WxDxH)	1304 x 1100 x 1062 mm
