Canon imagePROGRAF iPF8000S Service Manual

Chapter 6
6-15
T-6-28
40 GND - GND
41 H0-E-DATA-8-OD_B IN Odd head(R) data signal 8(E)
42 GND - GND
43 /H0-E-HE-8_B IN Head(R) heat enable signal 8(E)
44 GND - GND
45 H0-D-DATA-7-OD_B IN Odd head(R) data signal 7(D)
46 GND - GND
47 GND - GND
48 VH_MONI3 OUT VH control signal 3
49 GND - GND
50 GND - GND
J105
Pin Number Signal name IN/OUT Function
1 /H0-A-HE-0_B IN Head(R) heat enable signal 0(A)
2 GND - GND
3 H0-A-DATA-0-EV_B IN Even head(R) data signal 0(A)
4 GND - GND
5 /H0-A-HE-1_B IN Head(R) heat enable signal 1(A)
6 GND - GND
7 H0-A-DATA-1-EV_B IN Even head(R) data signal 1(A)
8 GND - GND
9 H0-B-DATA-2-EV_B IN Even head(R) data signal 2(B)
10 GND - GND
11 H0-B-DATA-3-EV_B IN Even head(R) data signal 3(B)
12 GND - GND
13 H0-C-DATA-4-EV_B IN Even head(R) data signal 4(C)
14 GND - GND
15 /H0-B-HE-3_B IN Head(R) heat enable signal 3(B)
16 GND - GND
17 /LIFT_CAM_IN OUT Lift cam sensor output signal
18 GND - GND
19 H0-C-DATA-5-EV_B IN Even head(R) data signal 5(C)
20 GND - GND
21 /H0_LT_B IN Head(R) latch signal
22 GND - GND
23 H0_CLKP IN Head(R) clock signal P
24 H0_CLKN IN Head(R) clock signal N
25 GND - GND
26 GND - GND
27 H0-DASLK_LICC2 IN Head(R) analogue switch clock signal
28 H0-DATA_LICC2 IN Head(R) analogue switch data signal
29 H0-DLD_LICC2 IN Head(R) analogue switch latch signal
30 GND - GND
31 H0-DSOUT1 OUT Head(R) temperature output signal 1
32 GND - GND
33 H0-DSOUT2 OUT Head(R) temperature output signal 2
34 GND - GND
35 H0-C-DATA-5-OD_B IN Odd head(R) data signal 5(C)
36 GND - GND
37 /H0-C-HE-5_B IN Head(R) heat enable signal 5(C)
38 GND - GND
39 /H0-D-HE-6_B IN Head(R) heat enable signal 6(D)
40 GND - GND
41 H0-D-DATA-6-OD_B IN Odd head(R) data signal 6(D)
42 GND - GND
43 H0-D-DATA-6-EV_B IN Even head(R) data signal 6(D)
44 GND - GND
45 H0-D-DATA-7-EV_B IN Even head(R) data signal 7(D)
46 GND - GND
47 /H0-D-HE-7_B IN Head(R) heat enable signal 7(D)
48 GND - GND
49 H0-E-DATA-8-EV_B IN Even head(R) data signal 8(E)
50 GND - GND
J104
Pin Number Signal name IN/OUT Function
