Canon imagePROGRAF iPF8000S Service Manual

Chapter 6
6-16
T-6-29
T-6-30
T-6-31
T-6-32
J201
Pin Number Signal name IN/OUT Function
1 ENCODER_B IN Linear encoder output signal B
2 GND - GND
3 ENCODER_A IN Linear encoder output signal A
4 SNS_5V OUT Power supply(+5V)
J202
Pin Number Signal name IN/OUT Function
1 SNS_5V OUT Power supply(+5V)
2 GND - GND
3 /CRCOVER IN Carriage cover sensor output signal
J701
Pin Number Signal name IN/OUT Function
1 H3V OUT Power supply
2 VH1_FB IN VH1 feed back voltage
3 VH1 OUT Power supply
4 VH1 OUT Power supply
5 VH1 OUT Power supply
6 VH1 OUT Power supply
7 VH1 OUT Power supply
8 VH1 OUT Power supply
9 GND - GND
10 GND - GND
11 GND - GND
12 GND - GND
13 GND - GND
14 GND - GND
15 GND - GND
16 VH2 OUT Power supply
17 VH2 OUT Power supply
18 VH2 OUT Power supply
19 VH2 OUT Power supply
20 VH2 OUT Power supply
21 VH2 OUT Power supply
22 VH2_FB IN VH2 feed back voltage
23 VHT OUT Power supply
24 GND - GND
25 GND - GND
J702
Pin Number Signal name IN/OUT Function
1 GND - GND
2 GND - GND
3 GND - GND
4 H1-B-DATA-3-EV OUT Even head(L) data signal 3(B)
5 GND - GND
6 /H1-B-HE-3 OUT Head(L) heat enable signal 3(B)
7 GND - GND
8 H1-C-DATA-4-EV OUT Even head(L) data signal 4(C)
9 GND - GND
10 H1-C-DATA-5-EV OUT Even head(L) data signal 5(C)
11 GND - GND
12 /H1-C-HE-5 OUT Head(L) heat enable signal 5(C)
13 GND - GND
14 H1-C-DATA-5-OD OUT Odd head(L) data signal 5(C)
15 GND - GND
16 H1-D-DATA-7-OD OUT Odd head(L) data signal 7(D)
17 GND - GND
18 H1-D-DATA-6-OD OUT Odd head(L) data signal 6(D)
