Nomenclature
<D> PC terminal (p.108)
<F>
Remote control terminal (N3 type) (p.103)
<H> Protect/Sound recording button
(p.123/124)/
<A> Picture Style setting button (p.57)
<L> Erase button (p.128)
<B> Info/Trimming
orientation button
(p.114, 116, 186/145)
LCD Monitor (p.41, 129)
<q> VIDEO OUT terminal (p.122)
Extension
system
terminal
Terminal
cover
<D> DIGITAL terminal (p.138, 152)
<M> Menu
button (p.41)
WFT-E2 II A/B/C/D
or WFT-E2/A
mounting hole
Rear LCD Panel (p.20)
<x> Playback button
(p.116)
<B> Function button (p.52, 63, 69, 73)
Recording microphone (p.124)
Battery compartment
cap (p.29)
Access lamp (p.34)
Memory card slot cover
release handle (p.32)
CF card eject
button (p.33)
SD card slot
(p.32)
CF card
slot (p.32)
Memory card
slot cover
(p.32)
Eyecup (p.39)
COPY
