COPIER > FUNCTION > INSTALL
Item Description
Title Setting of UGW port number when using Embedded-RDS
Details To set the port number of UGW to be used for Embedded-RDS.
Use case When using Embedded-RDS
Adj/set/operate method 1. Select the item, and then press Yes key.
2. Turn OFF / ON the main power switch.
Caution Be sure to use ERDS, RGW-PORT, COM-TEST, COM-RSLT, and COM-LOG as a set.
Display/adj/set range 1 to 65535
Default value 443
Related service mode COPIER > FUNCTION > INSTALL > ERDS
COPIER > FUNCTION > INSTALL > COM-TEST
COPIER > FUNCTION > INSTALL > COM-RSLT
COPIER > FUNCTION > INSTALL > COM-LOG
Supplement/memo Embedded-RDS: Function to send device information such as the device counter, failure, and con-
sumables to UGW via SOAP protocol
UGW (Universal Gate Way): Remote monitoring service system
COM-TEST
Title Execution of Embedded-RDS communication test
Details To execute Embedded-RDS communication test. If the connection fails, the information is added to the
communication error log.
Use case When using E-RDS
Adj/set/operate method Select the item, and then press Yes key.
Caution Be sure to use ERDS, RGW-PORT, COM-TEST, COM-RSLT, and COM-LOG as a set.
Display/adj/set range 0 to 1
Default value 0
Related service mode COPIER > FUNCTION > INSTALL > ERDS
COPIER > FUNCTION > INSTALL > RGW-PORT
COPIER > FUNCTION > INSTALL > COM-RSLT
COPIER > FUNCTION > INSTALL > COM-LOG
Supplement/memo Embedded-RDS: Function to send device information such as the device counter, failure, and con-
sumables to UGW via SOAP protocol
UGW (Universal Gate Way): Remote monitoring service system
COM-RSLT
Title Embedded-RDS communication test result
Details To display the Embedded-RDS communication test result.
Use case When using E-RDS
Adj/set/operate method N/A (Display only)
Caution Be sure to use ERDS, RGW-PORT, COM-TEST, COM-RSLT, and COM-LOG as a set.
Display/adj/set range When not in execution : Unknown, When connection is completed : OK, When connection is failed :
NG
Default value Unknown
Related service mode COPIER > FUNCTION > INSTALL > ERDS
COPIER > FUNCTION > INSTALL > RGW-PORT
COPIER > FUNCTION > INSTALL > COM-TEST
COPIER > FUNCTION > INSTALL > COM-LOG
Supplement/memo Embedded-RDS: Function to send device information such as the device counter, failure, and con-
sumables to UGW via SOAP protocol
UGW (Universal Gate Way): Remote monitoring service system
COM-LOG
Title Embedded-RDS communication error log
Details To display the Embedded-RDS communication error log. The dates, times, and error codes of the latest
5 errors that occurred are displayed. As for the error detail information, the report can be output by
executing COPIER > FUNCTION > MISC-P > ERDS-LOG.
Use case When using Embedded-RDS
Caution Be sure to use ERDS, RGW-PORT, COM-TEST, COM-RSLT, and COM-LOG as a set.
Display/adj/set range Date : 6 digits Time : 4 digits Error code : 8 digits
