PC-D320/PC-D340/FAX-L400 Chapter 4: Maintenance and Service
4-54
[Bit 2]
If ANSam signal is not received during transmission, select whether to use the V.8
protocol when the other fax machine declares the V.8 protocol in DIS signal. If “NO” is
selected, the CI signal is not transmitted and the V.8 protocol is not used even if the DIS
that specifies the V.8 protocol is received.
[Bit 3]
Select whether to declare the V.8 protocol in DIS signal for reception. If “NO” is
selected, the V.8 protocol cannot be used because it is not declared in DIS signal.
[Bit 4]
Select whether the reception side falls back during V.34 reception. If Prohibited is
selected, the reception side does not fall back.
[Bit 5]
Select whether the transmission side falls back during V.34 transmission. If Prohibited is
selected, the transmission side does not fall back.
SW33 (service soft switch 33: counter related)
Bit Function 1 0
0 (New) Count B4 as large size Yes No
1 (New) Indicate serial No. on counter Yes No
check screen
2 Not used
3 Not used
4 Not used
5 Not used
6 Not used
7 Not used
[Bit 0]
Use it to specify whether B4 paper should be count as large-size paper. If “Yes” is
selected, B4 paper will be counted as large-size paper. If “No” is selected, on the other
hand, B4 paper will be counted as small-size paper.
[Bit 1]
Use it to specific whether to indicate the machine serial No. on the Counter Check screen,
appearing when the Counter button is pressed. If “Yes” is selected, the serial No. will be
indicated. If “No” is selected, on the other hand, the serial No. will not be indicated.
