PC-D320/PC-D340/FAX-L400 Chapter 4: Maintenance and Service
4-55
#2 MENU
No. Function
Selection range Default setting
008 V.34 max. baud rate 2400~3429
3429 (3429 baud)
009 V.34 max. transmission speed 2.4~33.6 33.6 (33.6 kbps)
[No. 008]
Select the maximum baud rate for V.34 transmission: 3429, 3200, 3000, 2800, 2743, and
2400.
NOTE
This model cannot use 2743 baud due to its modem specification. If it is set
to 2743 baud, the maximum baud rate is 2400 baud.
[No.009]
Select the maximum transmission speed for V.34 transmission: 2.4 to 33.6 kbps.
#3 NUMERIC PARAM. (numeric parameter settings)
No. Function
Selection range Default setting
028 Menu selection screen display 1~60 3 (3 sec)
time length
[No.028]
Use it to set the length of time during which the Menu Select screen is indicated on the
LCD.
