Canon XA30 - Activating the Microphones Attenuator (INPUT Terminals)

Recording Audio
91
1 Open the desired INPUT terminal’s sensitivity submenu.
[FUNC.] > [MENU] > p > [INPUT 1 Mic Trimming] or [INPUT 2 Mic Trimming]
2 Touch the desired level and then touch [X].
• The available sensitivity levels are +12 dB, +6 dB, 0 dB, -6 dB and -12 dB.
Activating the Microphone’s Attenuator (INPUT terminals)
You can activate the microphone attenuator (20 dB) for microphones connected to the INPUT 1 and
INPUT 2 terminals to prevent audio from being distorted if the audio level is too high.
POINTS TO CHECK
• Set the sensitivity switch of the desired INPUT terminal to MIC or MIC+48V.
1 Open the desired INPUT terminal’s microphone attenuator submenu.
[FUNC.] > [MENU] > p > [INPUT 1 Mic Att.] or [INPUT 2 Mic Att.]
2Touch [i On] and then touch [X].
