Canton Smart Sounddeck 100 Short Manual

3
29
English
DISPLAY INDICATIONS
The Sounddeck 100 has an On-screen display (menu visible on the TV), a LED
status indicator (green or red) and a LED display (in the front of the Sound-
deck 100).
On-Screen display
All settings and the configuration of the Sounddeck 100 can be conveniently
performed via the On-screen display on your TV screen. To do this, the Sound-
deck 100 must be connected to your TV via a HDMI
®
cable. The menu is simple
and structured and all changes you make on the Sounddeck 100 are displayed
on your TV. By pressing the menu button (M) on the Smart-remote, you can
access the main menu.
Practical tip:
• To change the language of the On-screen display from German to English,
please go to the main menu by pressing the button „M“. Under „System-
einstellung“ [SYS] select the menu item „Displayeinstellungen“ [UIS] and
change the language under the menu item „Sprache“ [LAN].
LED status indicator
When you switch on the Sounddeck 100, the Status LED lights up green. In
standby mode, the Status LED lights up red.
LED display
The LED display is located in the front of the Sounddeck 100 and lights up for
five seconds when a command is sent. It indicates the selected function as
abbreviation or scroll text. The most important display indications and their
meanings are listed here:

Canton Smart Sounddeck 100 Specifications

General

Audio decoders	Dolby Atmos
RMS rated power	- W
Audio output channels	- channels
Audio Return Channel (ARC)	Yes
Wi-Fi	-
HDCP version	2.2
HDMI ports quantity	4
Connectivity technology	Wired
Product color	Black
Wall mountable	No
Audio formats supported	DTS

Weight and Dimensions

Width	- mm
Soundbar weight	- g
