Canton Smart Sounddeck 100 Short Manual

32
English
CONNECTION TO TV DEVICE
HDMI
®
(recommended)
1
Connect a HDMI
®
cable from the HDMI OUT (ARC) output on the back of
the Sounddeck 100 to the HDMI IN (eARC/ARC) input on your TV.
2
Now select the input [TV] by the Smart-remote using the up or down
arrow key ( / ) .
Notes:
• A HDMI
®
connection supports digital audio and video with a single cable.
It is the best option to connect your Sounddeck 100.
• If your TV features a HDMI
®
ARC/eARC connector, you can enjoy also the
TV internal audio through your Sounddeck 100 by using this HDMI
®
cable.
• This HDMI
®
connection is required if you intend to connect other video de-
vices to the Sounddeck 100 inputs to display on your TV.
• In this case, activate CEC mode on your TV. CEC (Consumer Electronics
Control) is a feature that allows compatible devices to be controlled from
a single remote control. For details, refer to the instruction manual of your
TV.
Optical digital input (alternative)
1
Connect the input OPTICAL on the Sounddeck 100 to the OPTICAL OUT
connector of your TV with an optical cable.
2
On the Smart-remote, use the up and down arrows ( / ) to select the
input [CD].
Note:
• Make sure you have removed the protective caps from both ends of the
optical cable.

Canton Smart Sounddeck 100 Specifications

General

Audio decoders	Dolby Atmos
RMS rated power	- W
Audio output channels	- channels
Audio Return Channel (ARC)	Yes
Wi-Fi	-
HDCP version	2.2
HDMI ports quantity	4
Connectivity technology	Wired
Product color	Black
Wall mountable	No
Audio formats supported	DTS

Weight and Dimensions

Width	- mm
Soundbar weight	- g
