Canton Smart Sounddeck 100 Short Manual

42
English
TECHNICAL DATA
Power supply
• Operating voltage 100–240V~
• Operating frequency 50/60Hz
• Power consumption ECO Standby 0.40W
• Power consumption NSB Standby WLAN [WIF] ca. 1.9W (Factory setting)
• Power consumption NSB Standby LAN [ETH] ca. 6.6W
• Power consumption AUT Standby ca. 6.6W
• Power consumption MAN Standby ca. 4.2W
• Power consumption in idle mode (no output signal) ca. 9.8W
• Power consumption maximal ca. 150W
Bluetooth® Wireless Technology
• Bluetooth® standard 4.1 (A2DP)
• Distance Up to 10m
• Max. transmission power 100mW (+20dBm)
• Frequency range 2402–2480MHz (ISM band)
• Antenna gain 4.2dBi
WLAN
• Max. transmission power 100mW (+20dBm)
• Frequency range 2412–2472MHz (802.11b/g/n)
5150–5350MHz and 5470–5725MHz (802.11a/n/ac)
• Antenna gain 4.2dBi @ 2.4GHz, 4.5dBi @ 5GHz
Wireless Audio
• Max. transmission power 100mW (+20dBm)
• Frequency range 2402–2480 MHz (2412MHz, 2438MHz and 2464MHz)
5180–5240 MHz (5180MHz, 5210MHz and 5240MHz)
5736–5814 MHz (5736MHz, 5762MHz and 5814MHz)
• Antenna gain 4.2dBi @ 2.4GHz, 4.5dBi @ 5GHz
Decoder
• Dolby Atmos
®
• DTS-HD
®
• PCM (32kHz-96kHz, 8Bit-24Bit)
Dimensions:
W: 100cm
H: 7cm
D: 33cm
Weight:
12,3kg
Ambient temperature
• Minimum 5°C (41°F)
• Maximum 35°C (95°F)

Canton Smart Sounddeck 100 Specifications

General

Audio decoders	Dolby Atmos
RMS rated power	- W
Audio output channels	- channels
Audio Return Channel (ARC)	Yes
Wi-Fi	-
HDCP version	2.2
HDMI ports quantity	4
Connectivity technology	Wired
Product color	Black
Wall mountable	No
Audio formats supported	DTS

Weight and Dimensions

Width	- mm
Soundbar weight	- g
