CanyCom CM 2103 - Stopping; How to Park

Operation
- 21 -
6.4 Stopping
1. Shift the accelerator lever to "LOW" to decrease engine
revolution speed.
Accelerator lever
H L
5314M-0602-080E
HST pedal
Parking brake lock lever
Brake pedal
5314M-0602-010E
5314M-0602-040E
Blade clutch lever
ON OFF
5314M-0602-020E
3. With the brake pedal depressed, pull the parking brake
lock lever toward operator to lock the parking brake.
2. Move foot off the HST pedal to stop the machine.
6.5 How to Park
1. Stop the machine under the procedures shown in item
6.4 “Stopping Procedure”.
2. Push the blade clutch lever to "OFF".
* Blade may still turn after brake is in "OFF" position due to inertia. Always confirm
that blade has stopped turning before dismounting machine. Dismount after the
blade has completely stopped.
