6.3 Operation Procedure
1. Check the area around the machine for safety.
2. Release the parking brake lock lever.
Parking brake lock lever
Brake pedal
5314M-0603-010E
5314M-0602-010E
L N H
Auxiliary speed change lever
5314M-0603-030E
5314M-0603-020E
L H
Auxiliary speed change lever
5314M-0603-040E
5. To accelerate, press the HST pedal slowly.
To move forward : Push the pedal top.
To move backward : Push the pedal bottom.
3. Shift the accelerator lever to "HIGH" to increase the
engine speed.
4. Shift the auxiliary speed change lever to “LOW” to
decrease engine speed.
To change speeds:
When conditions require speed changes, shift the
auxiliary speed change lever between "HIGH" and
"LOW".
* Avoid shifting auxiliary speed change lever
when machine is moving to prevent failure or
damage.
