Operation
-30-
4
1. Stop machine.
2. Move auxiliary transmission shift lever to [H
(high speed)] or [L (low speed)] position rmly.
5347M-0402-100E
Auxiliary
Transmission
Shift Lever
L
H
N
• See Specications (page 15) for the speed
range in either gear position.
• Always stop machine to shift gears. Shifting gears while machine is in motion
can damage transmission.
• Use [L] mode when mowing. Mowing in [H] mode can put excessive strain and
damage the mowing mechanism.
NOTE
• Always shift gears rmly. When transmission is not rmly shifted, it may jump
out of gear, resulting in loss of control of machine.
Shifting
5347M-0402-120E
Brake Pedal
3. Depress brake pedal to stop machine
completely.
• When brake pedal is depressed, drive lever
returns to neutral position.
NOTE
To Next Page
