-53-
Maintenance 5
Seat Bracket
1. Slide seat to the rear-most position.
2. Lift seat and push safety pin toward inside to
hold seat.
• Move seat and check if the seat is held in
place rmly.
NOTE
5332M-0401-080E
Safety Pin
Cutting Blade Shield
• Always slide seat to the rear-most position when lifting seat. If seat is not in the
rear-most position, slide lever may interfere with step, preventing seat to be
lifted to the holding position.
• Make sure cutting blade shield is securely locked in the lowest position and
does not open to the side. Loose shield may allow objects to be thrown,
resulting in injury to the operator or by-standers or in property damage.
• Stop engine before opening cutting blade shield. Opening shield when cutting
blade is moving may result in injury or death.
To Next Page
