Maintenance
-76-
5
Light Bulbs
• When light bulb is burnt out, replace it with a new bulb.
• When replacing, always use a bulb of the correct rating. Wrong bulb may cause
malfunction or damge in electrical system.
• Do not touch bulb when it is hot. It may cause burns.
• Do not touch the glass part of light bulb directly with fingers. It may reduce
service life.
1. Remove 2 screws and remove lens.
Rear Lamp (AWD Models)
5332M-0509-070E
Lens
• Light Bulbs to use: Page 50.
NOTE
Head Lamp
Socket
Light Bulb
5332M-0508-050E
1. Remove front cover and head lamp unit.
2. Turn socket to remove.
3. Replace with new light bulb.
4. Install socket.
5. Install head lamp and front cover.
To Next Page
