-75-
Maintenance 5
5332M-0509-020E
Main Fuse
Fuse Case
Cap
Lights Fuse
1. Open engine hood.
2. Open fuse case cap. Remove fuse and
visually inspect. If it is blown, replace it with
new one of the same rating.
3. Install fuse.
4. Install fuse case cap.
5. Close engine hood.
Fuses
• If a fuse blows, investigate the cause before replacing.
• Always replace a fuse with one of the correct rating.
• Main Fuse: 30A. Lights Fuse: 10A
• Replacement Fuse: Page 50.
NOTE
Filling
UPPER LEVEL
LOWER LEVEL
Filler Cap
5321M-0510-020E
1. Remove front cover.
2. Remove battery.
3. Remove ller cap.
4. Fill distilled water to "UPPER LEVEL" line.
5. Install ller cap.
6. Install battery.
7. Install front cover.
5116M-0509-040E
1. Remove front cover.
2. Remove battery from machine.
3. Follow instructions in battery charger user's
manual to charge battery.
4. When battery is fully charged, install battery
back in place.
5. Install front cover back in palce.
Charging
To Next Page
