Controls and Components
-10-
2
Shift Lever
6 Starter Handle. . . . . . . . . . . . Starter Handle is used to start engine.
7 Fuel Valve Lever . . . . . . . . . . Fuel valve lever opens or shuts fuel ow.
8 Shift Lever. . . . . . . . . . . . . . . Shift Lever is used to shift gears.
9 Auxiliary Transmission . . . . Auxiliary Transmission Shift Lever is used to select fast or
slow driving mode.
10 Dump Levers . . . . . . . . . . . . Dump Lever is used to dump loading deck. Dump Lever
raises or lowers loading deck. Dump Lever raises loading
deck for dumping or lowers it from that position. There are
two dump levers; one behind loading deck (deck lever)
and one on the handlebar (handlebar lever).
