CanyCom SC45 - Using Safety Lock Plate

Operation
-28-
4
• When it is necessary to inspect or work under loading deck, raise loading deck
to do so. Never work under loading deck when it is in the dumping position.
• Hold loading deck in the raised position with safety lock plate when inspecting
or working under loading deck.
• Make certain that safety lock plate securely hooks crossmember. Loose safety
lock plate may result in injury or death.
• Make certain to undo safety lock plate before lowering loading deck.
Using Safety Lock Plate
1. Raise the loading deck.
2. Remove the pin then remove the safety lock
plate.
3577M-0403-020US
Safety Lock Plate
3. Mount safety lock plate following the picture
on the left to x loading deck rmly.
3577M-0403-030US
Safety Lock Plate
Pin
