Maintenance
-44-
5
Hydraulic System
Hydraulic Package
• Make certain to ll hydraulic package with specied uid to the specied level.
Insufficient amount or wrong grade of fluid reduces performance and may
cause permanent damage to engine.
• Dispose of drained oil and uids properly.
• Stop engine when servicing drive train.
• Allow machine to cool off before servicing. Engine is very hot after operation
and may pose a burn hazard.
• To obtain correct reading, check hydraulic fluid level with loading deck in the
lowered (not dumped) position.
• Always check hydraulic uid level on a level ground.
• Recommended Oil and Quantity: see "List of Fluids and Lubricants" (page 32)
NOTE
1. Park machine on a level ground.
2. Visually inspect the hydraulic fluid level.
Make certain the uid level is above 600 line.
3. If uid level is low, ll uid.
Inspecting
3577M-0507-010US
Fluid Tank
Fluid Level
To Next Page
