Maintenance
-42-
5
• Always keep brake adjusted for maximum performance. Improperly adjusted
brakes may result in property damage, serious injury, or death.
Parking Brake
1. Remove fender.
2. Move drive clutch lever to [Stop] position.
3. Inspect that the amount of stretch on brake
spring is 3-4 mm. If it is not, adjust with
adjust nuts.
4. Install fender.
Adjust Nuts Spring
3577M-0506-060US
