-43-
Maintenance 5
Side Clutch
1. Raise loading deck and support it with
loading deck safety lock plate.
2. Adjust side clutch with adjust nut so that the
play on side clutch lever is between 1 and 5
mm.
3. Undo safety lock plate and lower loading
deck.
Lubrication
• Follow the maintenance schedule to lubricate machine. Lack of lubrication may
result in rust, excessive wear or seizure.
Greasing Point
1. Remove fender.
2. Apply specied grease on the greasing point.
3. Install fender.
Adjust Nuts
3577M-0506-080US
To Next Page
