-37-
Maintenance 5
Air Cleaner
• Clean air cleaner element regularly. Dirty air cleaner element reduces engine
performance and life.
• Replace air cleaner element if damaged.
1. Follow the instructions in "Operator's
Manual for the Engine" to clean or replace
air cleaner element.
Filling
1. Remove oil ller cap.
2. Follow the instructions in "Operator's
Manual for the Engine" to ll oil.
3. Check oil level.
4. Screw oil ller cap rmly back in place.
Changing
1. Have an appropriate oil drain pan.
2. Raise loading deck and set safety lock plate
3. Remove oil drain plug and drain oil.
4. Put drain plug back in place.
5. Fill oil.
6. Release safety lock plate and lower loading
deck.
Drain Plug
3577M-0505-020US
3577M-6107-0505-030
Air Cleaner
3577M-6107-0505-010
Oil Filler Cap
To Next Page
