Drive Chain Maintenance
The service life of the chain greatly depends on the maintenance. Refer to the following contents:
Chain inspection for defects
■ Clean the chain
● Rinse large stains with a gentle water beam.
● Remove lubricant residue wit chain detergent.
● Spray chain lubricating spray after drying.
■ Replace the chain
■ Check the rubber cushion and chain guide.
If the chain is too tight, it will accelerate the wear of the
front sprocket, the rear chain disc, the chain guide, the
rubber cushion and the tensioner, and it may be broken or
damaged locally.
■ Loose chain:
The loose chain may fall off the chain disc; the chain guide
can prevent the chain from falling off, provided that the
chain guide is intact; the falling chain may damage the chain
guide.
Regular inspection or replacement of tensioner and rubber
cushion can prevent chain wear and detaching.
Damage and
rust
Loose
chain pin,
stuck link
Rinse gently with
water
Chain detergent
Severe contamination
If the rubber cushion falls off
or the smooth part is worn, they
should be replaced.
Replace the chain guide
Suspend the rear wheel by the lifting platform and
remove it. The chain guide is equipped with the left bush
of rear wheel. After installing the chain guide, install the
right bush, the disc brake support and the chain adjusting
top block in turn, and sleeve and tighten the rear wheel
shaft. There are two kinds of chain guide, the size of
which is determined according to rear sprocket size.
Slowly turn the rear wheel, check the
front and rear sprockets, and replace
them in case of abnormal sound and
wear, as shown in the right figure.
