15. Torque of Motorcycle Components
Location Specification Torque Value Management Tools Remarks
Nut for rear axle
Self-locking nut M12×1.25
50Nm 18mm socket/M8 Allen wrench
Brake disc Bolt M6X12 20Nm T30 hexagonal box wrench Thread fixing glue
Rear sprocket
Step bolt M6×18
30Nm T30 hexagonal box wrench Thread fixing glue
Brake caliper bolt Bolt M6X25 25Nm T30 hexagonal box wrench Thread fixing glue
Chain adjusting bolt
Round head bolt M6×35
15Nm M10 solid wrench
Nut for front axle
Bolt M14×15
15Nm 19mm socket/M12 Allen wrench
Front axle locking bolt Bolt M6X20 15Nm T30 hexagonal box wrench
Locking bolt between steering
stem and front shock absorber
Bolt M6X20 15Nm T30 hexagonal box wrench
Locking bolt between triple
clamp and front shock absorber
Bolt M6X20 20Nm T30 hexagonal box wrench
Handlebar seat locking bolt Bolt M6X20 20Nm T30 hexagonal box wrench Thread fixing glue
Handlebar end cap locking bolt Bolt M6X20 15Nm T30 hexagonal box wrench
Triple clamp locking bolt Bolt M6X30 15Nm T30 hexagonal box wrench
Battery installation Bolt M8X20 25Nm T40 double offset ring spanner
Controller bolt Bolt M6X20 10Nm T30 hexagonal box wrench
Motor installation Bolt M8X20 25Nm T40 double offset ring spanner
Minor sprocket mounting bolt
Bolt M6×10
25Nm T30 hexagonal box wrench
Burglar alarm holder bolt Bolt M6X12 15Nm T30 hexagonal box wrench
Burglar alarm mounting bolt Bolt M6X12 10Nm T30 hexagonal box wrench
DC/DC converter bolt Bolt M6X12 15Nm T30 hexagonal box wrench
Rear fork shaft nut
Self-locking nut M12×1.25
45Nm 18mm socket/M8 Allen wrench
Rear shock absorber
installation
Self-locking nut M8×1.25
30Nm T40 double offset ring spanner/13mm socket
or wrench
Thread fixing glue
Side stand nut
Self-locking nut M0×1.25
25Nm 15mm, 16mm socket or wrench
Pedal mounting bolt Bolt M10X 50 30Nm M8 Allen wrench
Tensioner nut
Self-locking nut M0×1.25
30Nm T40 double offset ring spanner\15mm socket
or wrench
