14. Technical Parameters of the Motorcycle
MotorcycleParameters
LxWxH
1970mmx780mmx1080mm（F80L1e）
2000mmx780mmx1080mm（F80L3e）
Wheel base 1310mm
Seat height
825/840mm (different tire specifications)
Ground clearance
260mm/270mm (different tire specifications)
Curb weight 84kg/78kg
Load capacity 100kg
Max. allowable total weight 184kg/178kg
Max. design speed 85km/h-100km/h
Max. Climbing Capacity
≥40°
Braking deceleration According to GB20073
Motor Air cooled PM synchronous; maximum power: 8kW
Battery pack available
72V48Ah、72V32Ah）、72V30Ah
Controller Type: air-cooled sine wave; maximum current: 125A
Frame Aluminum alloy integral die-casting frame
Suspension/brake system
Front damping system HTWF80; spiral spring/mixed oil-gas adjustable inverted shock absorber, 200mm stroke
Rear suspension system HTWF80; spiral spring/single mixed oil-gas adjustable rear absorber, 85mm stroke
Available front hub specifications Aluminum alloy; 1.6-19/1.85-18
Available rear hub specifications Aluminum alloy; 1.85-18/2.15-18/2.15-16
Available front tire Front tire 2.25-19, 2.75-18, 3.00-18, 70/100-19 (off-road)
Available rear tire
Rear tire 2.75-18, 80/100-18, 3.00-18 (off-road) 、90/100-16(off-road)
Front hydraulic brake system Disc brake operated by right hand
Front brake disc diameter 203mm/230mm hydraulic single disc
Rear hydraulic brake system Disc brake operated by left hand
Rear brake disc diameter 203mm hydraulic single disc
Road tire pressure Off-road tire pressure
